Type of sensors on injectors lines – oval gear flow meter
Type of sensors on pumps lines – turbine flow meter
Flow measuring range (injectors delivery) – from 0,5 to 830 cc/min
Flow measuring range (pumps) – from 0.1 up to 2.5 l/min
Two temperature sensors are set on each injectors channel and measure the
temperature of test oil on the entrance of device and on the entrance of flow sensor.
On the pump lines is set one temperature sensor on the entrance of device.
|
